NBX13907
Thin Section Bearing
NBX13907 thin section bearing Dentification
N: Series
B: Ball bearing (thin section bearing)
X: Bearing Type_four point contact
Bore: 139.700 (mm)
Width: 7.938 (mm)
Please download rough drawing of thin section bearing for reference,formal drawing of thin section bearing NBX13907 will be submitted after contact with sales@jcb-bearing.com
Part number comparison
Same As Specification Of NBX13907 Following Bearing Designation | |||||
KB055XP0 | KB055XP0*JCB | CSXB055 | NBX13907 | RB055XP0 | SB055XP0 |
NBX13907 Thin Section Bearing Specifications
Inner Diameter (d) | 5.500″ |
Inner Diameter Tolerance | -0.0010″- 0″ |
For Housing ID | 6.125″ |
Outer Diameter (D) | 6.125″ |
Outer Diameter Tolerance | -0.0010″- 0″ |
Width (B) | 0.3125″ |
Width Tolerance | +.000 –.005″ |
Bearing type | Four Point contact ball |
Contact Angle | |
Seal Type | Open |
Cross Section | 5/16″ x 5/16″ |
Weight(lbs) | 0.410 |
Internal clearance | C0 |
Operating temperature range | -65 to +250 °F |
Radial dynamic load capacity | 1304 lbf |
Radial static load capacity | 2360 lbf |
Axial dynamic load capacity | 2460 lbf |
Axial static load capacity | 5890 lbf |
Bearing material | AISI 52100 |
Ring material | AISI 52100 |
Separator material | Brass/Composite |
Separator type | Circular Pocket |
Maximum rpm | 2060 rpm |
Bearings designation | – |
NBX13907 Thin Section Bearing Descriptions
1、BEARING INSIDE STRUCTURE :
NBA : Radial Type
NBC : Angular Type
NBX : Four-Point Contact Type
2、Bore Diameter:25.4-127.0 mm
3、SEPARATOR OR CAGE :
No Symbol : Pressed Brass Cage
T : Synthetic Resin Cage
4、SEAL SYMBOL :
No Symbol : Open Type
D : Sealed On One Side
DD : Sealed On Both Sides
5、INTERNAL CLEARANCE :
Nominal Bearing Bore Diameter(d:mm) | Single Plane Mean Bore Diameter Deviation(⊿dmp:μm) | Single Plane Mean Outside Diameter Deviation(⊿Dmp:μm) | Deviation of a Single Inner Ring Width(⊿Bs:μm) | Radial Internal Clearance(μm) | |||||
over | incl | high | low | high | low | high | low | min | max |
– | 25.400 | 0 | -10 | 0 | -13 | 0 | -127 | 25 | 38 |
25.400 | 38.100 | 0 | -13 | 0 | -13 | 0 | -127 | 30 | 43 |
38.100 | 63.500 | 0 | -15 | 0 | -13 | 0 | -127 | 30 | 56 |
63.500 | 76.200 | 0 | -15 | 0 | -15 | 0 | -127 | 30 | 56 |
76.200 | 101.600 | 0 | -20 | 0 | -15 | 0 | -127 | 41 | 66 |
101.600 | 114.300 | 0 | -20 | 0 | -20 | 0 | -127 | 41 | 66 |
114.300 | 127.000 | 0 | -25 | 0 | -20 | 0 | -127 | 51 | 76 |
127.000 | 165.100 | 0 | -25 | 0 | -25 | 0 | -127 | 51 | 76 |
165.100 | 177.800 | 0 | -25 | 0 | -30 | 0 | -127 | 51 | 76 |
177.800 | 228.600 | 0 | -30 | 0 | -30 | 0 | -127 | 61 | 86 |
226.600 | 304.800 | 0 | -36 | 0 | -36 | 0 | -127 | 71 | 97 |
304.800 | 355.600 | 0 | -36 | 0 | -36 | 0 | -254 | 71 | 97 |
355.600 | 457.200 | 0 | -41 | 0 | -41 | 0 | -254 | 81 | 107 |
457.200 | 762.000 | 0 | -46 | 0 | -46 | 0 | -254 | 91 | 117 |
762.000 | 1016.000 | 0 | -51 | 0 | -51 | 0 | -254 | 102 | 127 |
5、ACCURACY CLASS:
PK1 , PK3 , PK4
Similar Products Of NBX13907 Thin Section Bearing
Bearing No. | Bearing No. | Bearing No. |
NBX 13907 | NBX 13907 PK3 | NBX 13907 PK4 |
NBX 13907 D | NBX 13907 D PK3 | NBX 13907 D PK4 |
NBX 13907 DD | NBX 13907 DD PK3 | NBX 13907 DD PK4 |
NBX 13907 T | NBX 13907 T PK3 | NBX 13907 T PK4 |
NBX 13907 T D | NBX 13907 T D PK3 | NBX 13907 T D PK4 |
NBX 13907 T DD | NBX 13907 T DD PK3 | NBX 13907 T DD PK4 |
