NBX10719 thin section bearing
NBX10719
Thin Section Bearing
NBX10719 thin section bearing Dentification
N: Series
B: Ball bearing (thin section bearing)
X: Bearing Type_four point contact
Bore: 107.950(mm)
Width: 19.050 (mm)
Please download rough drawing of thin section bearing for reference，formal drawing of thin section bearing NBX10719 will be submitted after contact with sales@jcb-bearing.com
Part number comparison
| Same As Specification Of NBX10719 Following Bearing Designation | |||||
| KF042XP0 | KF042XP0*JCB | CSXF042 | NBX10719 | RF042XP0 | SF042XP0 |
NBX10719 Thin Section Bearing Specifications
| Internal clearance | C0 |
| Operating temperature range | -65 to +250 °F |
| Radial dynamic load capacity | 4795 lbf |
| Radial static load capacity | 5640 lbf |
| Axial dynamic load capacity | 8990 lbf |
| Axial static load capacity | 14110 lbf |
| Bearing material | AISI 52100 |
| Ring material | AISI 52100 |
| Separator material | Brass/Composite |
| Separator type | Circular Pocket |
| Maximum rpm | 2400 rpm |
| Bearings designation | – |
| Internal clearance | – |
| Operating temperature range | – |
| Radial dynamic load capacity | request by email |
| Radial static load capacity | – |
| Axial dynamic load capacity | request by email |
| Axial static load capacity | – |
| Bearing material | – |
| Ring material | – |
| Separator material | – |
| Separator type | – |
| Maximum rpm | – |
| Bearings designation | – |
NBX10719 Thin Section Bearing Descriptions
1、BEARING INSIDE STRUCTURE ：
NBA : Radial Type
NBC : Angular Type
NBX : Four-Point Contact Type
2、Bore Diameter:25.4-127.0 mm
NBX10719 thin section bearing
3、SEPARATOR OR CAGE ：
No Symbol : Pressed Brass Cage
T : Synthetic Resin Cage
4、SEAL SYMBOL :
No Symbol : Open Type
D : Sealed On One Side
DD : Sealed On Both Sides
5、INTERNAL CLEARANCE :
| Nominal Bearing Bore Diameter(d:mm) | Single Plane Mean Bore Diameter Deviation(⊿dmp:μm) | Single Plane Mean Outside Diameter Deviation(⊿Dmp:μm) | Deviation of a Single Inner Ring Width(⊿Bs:μm) | Radial Internal Clearance(μm) | |||||
| over | incl | high | low | high | low | high | low | min | max |
| – | 25.400 | 0 | -10 | 0 | -13 | 0 | -127 | 25 | 38 |
| 25.400 | 38.100 | 0 | -13 | 0 | -13 | 0 | -127 | 30 | 43 |
| 38.100 | 63.500 | 0 | -15 | 0 | -13 | 0 | -127 | 30 | 56 |
| 63.500 | 76.200 | 0 | -15 | 0 | -15 | 0 | -127 | 30 | 56 |
| 76.200 | 101.600 | 0 | -20 | 0 | -15 | 0 | -127 | 41 | 66 |
| 101.600 | 114.300 | 0 | -20 | 0 | -20 | 0 | -127 | 41 | 66 |
| 114.300 | 127.000 | 0 | -25 | 0 | -20 | 0 | -127 | 51 | 76 |
| 127.000 | 165.100 | 0 | -25 | 0 | -25 | 0 | -127 | 51 | 76 |
| 165.100 | 177.800 | 0 | -25 | 0 | -30 | 0 | -127 | 51 | 76 |
| 177.800 | 228.600 | 0 | -30 | 0 | -30 | 0 | -127 | 61 | 86 |
| 226.600 | 304.800 | 0 | -36 | 0 | -36 | 0 | -127 | 71 | 97 |
| 304.800 | 355.600 | 0 | -36 | 0 | -36 | 0 | -254 | 71 | 97 |
| 355.600 | 457.200 | 0 | -41 | 0 | -41 | 0 | -254 | 81 | 107 |
| 457.200 | 762.000 | 0 | -46 | 0 | -46 | 0 | -254 | 91 | 117 |
| 762.000 | 1016.000 | 0 | -51 | 0 | -51 | 0 | -254 | 102 | 127 |
5、ACCURACY CLASS：
PK1 , PK3 , PK4
Similar Products Of NBX10719 Thin Section Bearing
| Bearing No. | Bearing No. | Bearing No. |
| NBX 10719 | NBX 10719 PK3 | NBX 10719 PK4 |
| NBX 10719 D | NBX 10719 D PK3 | NBX 10719 D PK4 |
| NBX 10719 DD | NBX 10719 DD PK3 | NBX 10719 DD PK4 |
| NBX 10719 T | NBX 10719 T PK3 | NBX 10719 T PK4 |
| NBX 10719 T D | NBX 10719 T D PK3 | NBX 10719 T D PK4 |
| NBX 10719 T DD | NBX 10719 T DD PK3 | NBX 10719 T DD PK4 |
