NBC10125

Thin Section Bearing

NBC10125 thin section bearing Dentification

N: Series

B: Ball bearing (thin section bearing)

C:Bearing Type_deep groove ball bearing

Bore: 101.600 (mm)

Width: 25.400 (mm)

Please download rough drawing of thin section bearing NBC10125 for reference,formal drawing of thin section bearing NBC10125 will be submitted after contact with sales@jcb-bearing.com

NBC10125 of thin section bearing.pdf

Part number comparison

Same As Specification Of NBC10125 Following Bearing Designation
KG040CP0KG040CP0*JCBCSCG040NBC10125RG040CP0SG040CP0

NBC10125 thin section bearing specifications

Inner Diameter (d)4.000″
Inner Diameter Tolerance-0.0008″– 0″
For Housing ID6.000″
Outer Diameter (D)6.000″
Outer Diameter Tolerance-0.0006″– 0″
Width (B)1″
Width Tolerance+.000 –.005″
Bearing typeRadial contact ball
Contact Angle
Seal TypeOpen
Cross Section1″ x 1″
Weight(lbs)3.600
Internal clearanceC0
Operating temperature range-60 to 250 °F
Radial dynamic load capacity6700 lbf
Radial static load capacity8210 lbf
Axial dynamic load capacity
Axial static load capacity
Bearing materialAISI 52100
Ring materialAISI 52100
Separator materialBrass/Non-Metallic
Separator typeCircular Pocket
Maximum rpm4000 rpm
Bearings designation

NBC10125 Thin Section Bearing Descriptions

1、BEARING INSIDE STRUCTURE :

NBA : Radial Type

NBC : Angular Type

NBX : Four-Point Contact Type

2、Bore Diameter:25.4-127.0 mm
NBC10125 THIN SECTION BEARING

NBC10125 THIN SECTION BEARING

3、SEPARATOR OR CAGE :

No Symbol : Pressed Brass Cage

T : Synthetic Resin Cage

4、SEAL SYMBOL :

No Symbol : Open Type

D : Sealed On One Side

DD : Sealed On Both Sides

5、INTERNAL CLEARANCE :
Nominal Bearing Bore Diameter(d:mm)Deviation of a Single Inner Ring Width(⊿Bs:μm)Single Plane Mean Bore Diameter Deviation(⊿dmp:μm)Single Plane Mean Outside Diameter Deviation(⊿Dmp:μm)Radial Internal Clearance(μm)
overinclhighlowhighlowhighlowminmax
25.4000-1270-100-132541
25.40038.1000-1270-130-133046
38.10063.5000-1270-150-133061
63.50076.2000-1270-150-153061
76.200101.6000-1270-200-154171
101.600114.3000-1270-200-204171
114.300127.0000-1270-250-205186
127.000165.1000-1270-250-255186
165.100177.8000-1270-250-305186
177.800228.6000-1270-300-3061107
226.600304.8000-1270-360-3671122
304.800355.6000-2540-410-4181132
355.600457.2000-2540-460-4691142
457.200508.0000-2540-510-51102152
508.000762.0000-2540-760-76152203
5、ACCURACY CLASS:

PK1 , PK3 , PK4

Similar products of NBC10125 thin section bearing

Bearing No.Bearing No.Bearing No.
NBC 10125NBC 10125 PK3NBC 10125 PK4
NBC 10125 DNBC 10125 D PK3NBC 10125 D PK4
NBC 10125 DDNBC 10125 DD PK3NBC 10125 DD PK4
NBC 10125 TNBC 10125 T PK3NBC 10125 T PK4
NBC 10125 T DNBC 10125 T D PK3NBC 10125 T D PK4
NBC 10125 T DDNBC 10125 T DD PK3NBC 10125 T DD PK4
